“My 3D printing journey has been a roller coaster ride until I found Asiga. My Asiga 3D printers provide the most reliable and accurate output compared to any other equipment in my lab. If you are looking for perfect 3D prints day in, day out then you will not find a better investment.”
Przemek Seweryniak,
Cosmodent AB, Sweden
Globally proven layer
formation technologies
Every single layer formed under a closely monitored process delivering exceptional consistency and performance.
Active Layer Monitoring
Asiga’s pioneering Smart Positioning System (SPS™) achieves precise layer thickness control of each and every layer, ensuring optimal print accuracy and speed.
DLP Micromirror Technology
Achieve the highest standard of reliability with the broadest wavelength capability of any imaging technology.
Auto-Calibrating UV LED
Combining the latest generation of high-power ultraviolet solid-state light sources with an integrated radiometer ensures years of consistent printing performance.
385nm LED as standard.
“The Asiga Max provides our laboratory consistent results for all 3D printed applications. Eliminating the variability in our printing has greatly streamlined our manufacturing output.”
Lachlan Thompson,
Omni Dental
Small in size. Big on features.
A simple user interface
Navigate to your next build easily and then follow the prompts.
The UI on the Max 2 will walk you through the process of starting the printer with simple messaging and clear infographics.
Transparent Mode™
True water-clear resins can now be printed with extreme precision.
Printing clear materials has never been this accurate.
Chamber heating
Take advantage of a chamber heating system to warm your temperature sensitive materials ready for printing.
Also did you know, a little heat helps reduce material viscosity allowing you to print faster!
Material Freedom
Over 500 materials available.
Experience the widest choice of materials on the market with unlimited and unrestricted access to many industry-leading materials for a variety of applications. Future-proof your business and stay up-to-date with the latest validated 3D print materials thanks to Asiga’s Open Material Architecture.
Material Freedom
Over 500 materials available.
Experience the widest choice of materials on the market with unlimited and unrestricted access to many industry-leading materials for a variety of applications. Future-proof your business and stay up-to-date with the latest validated 3D print materials thanks to Asiga’s Open Material Architecture.
UltraGLOSS™
3D print parts directly with a glossy / pre-polished surface removing the need for manual post-polishing.
That’s right, no more manual polishing!
Unlimited lifetime technical support
Receive technical support from your local reseller and also from any of our global offices.
Asiga technical support if unlimited and free.
You can also visit our Customer Support Centre for training and self-help.
Powerful nesting software
Automatic build preparation software included with the Max 2. Asiga Composer is powerful nesting software, simple to use and free.
Compatible on Windows, MacOS and Linux.
Lifetime updates included.
Technical specifications
| Build Volume X, Y, Z | 119 × 67 × 75mm 4.69 × 2.64 × 2.95 inches |
| Pixel Resolution | 62µm |
| Technology | DLP |
| Auto-calibrating UV LED | 385nm (405nm available on request) |
| Material Compatibility | Use any one of over 500 qualified resins from the world's leading material manufacturers, or create your own. |
| Software | Asiga Composer software. Lifetime updates included |
| File Inputs | STL, SLC, PLY, STM (Asiga Stomp file format) |
| Network Compatibility | Wifi, Wireless Direct, Ethernet |
| Power Requirements | 12V 10A, 120W |
| System Sizing | 260 × 385 × 370mm / 19.3 kg 10.2 × 15.2 × 14.5 inches / 42.6 lb |
| Packed Sizing | 410 × 500 × 480mm / 21.6 kg 16.1 × 19.7 × 18.9 inches / 47.6 lb |
| Warranty | 12 months manufacturer's warranty |
| Technical Support | Unlimited lifetime technical support included |
| Bundle Includes | 3D printer, Composer software, 1 kg Asiga material, 1L build tray, Asiga Flash post-curing chamber, calibration toolkit |
What’s included
Included with your Max 2 is everything you need to start printing out of the box.
Including:
• Max 2 Printer
• Calibration toolkit
• Asiga material of your choice and build tray
• Asiga Flash curing chamber
• Composer software
• Unlimited lifetime technical support
